AT91SAM7X256-AU Real Image AT91SAM7X256-AU Real Image1 AT91SAM7X256-AU Real Image2
Same model may have multiple batches, images only for reference.
AT91SAM7X256-AU Real Image AT91SAM7X256-AU Real Image1 AT91SAM7X256-AU Real Image2
AT91SAM7X256-AU Real Image AT91SAM7X256-AU Real Image1 AT91SAM7X256-AU Real Image2
Same model may have multiple batches, images only for reference.

AT91SAM7X256-AU

Part No AT91SAM7X256-AU
Manufacturer Atmel
Catalog Embedded - Microcontrollers
Description MCU 16-bit/32-bit ARM7TDMI RISC 256KB Flash 1.85V/3.3V 100-Pin LQFP / IC MCU 32BIT 256KB FLASH 100LQFP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tray
Status Obsolete(EOL)
Core Processor ARM7
Part Core Size 16/32-Bit
Speed(Frequency) 55MHz
Number of I/O 62
Program Memory Size 256KB (256K x 8)
Program Memory Type FLASH
Data RAM Size 64K x 8
Supply Voltage - Operating 1.65 V to 1.95 V
Data Converters A/D 8x10b
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 100-LQFP (14x14)
Win Source Part Number 143576-AT91SAM7X256-AU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name AT91SAM7X256
Introduction Date May 02, 1997
ECCN 3A991.a.2
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian AT91SAM7X256-AU CAD Model

Description

Description

The AT91SAM7X256-AU is a versatile ARM7TDMI?-based microcontroller that targets a range of cost-sensitive networking and communications applications. With 256KB of high-speed Flash and 64KB of SRAM, it offers integrated Ethernet MAC, which is ideal for networked embedded systems.

Applications

  • Industrial Automation
  • POS Terminals
  • Data Acquisition Systems
  • Networking Gateways

Features and Benefits

  • Enhanced Connectivity Options: Includes Ethernet MAC and USB interfaces.
  • Robust Processing Power: 48 MHz ARM7TDMI? core for high performance.
  • Ample Memory: 256KB Flash and 64KB SRAM for efficient data processing.
  • Low Power Consumption: Optimized for low power and high efficiency in portable applications.

Additional Details

  • Comprehensive Development Tools: Supported by a wide range of development tools and IDEs.
  • Compact Package: Available in a 100-pin QFP package.
