Same model may have multiple batches, images only for reference.

ASA00B24-L

Name: ASA00B24-L
Brand: Artesyn Embedded Technologies
SKU: 564910
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	ASA00B24-L
Manufacturer	Artesyn Embedded Technologies
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 12V 10W
Datasheet	ASA00B24-L Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	Artesyn Embedded Technologies
Series	ASA (10W)
Package	Tube
Product Status	Obsolete
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	18V
Voltage - Input (Max)	36V
Voltage - Output 1	12V
Current - Output (Max)	835mA
Power (Watts)	10 W
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	SCP
Temperature Range - Operating	-40°C ~ 60°C
Efficiency	83%
Mounting Type	Through Hole
Package / Case	8-DIP Module
Size / Dimension	1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
Standard Package	200 pcs
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	564910-ASA00B24-L
Ultra Librarian 3D Model	Ultra Librarian ASA00B24-L CAD Model

Alternative Products

Description

The ASA00B24-L is a 10W isolated module power supply designed for board mount applications.

Series: ASA
Power Output: 10W
Size: 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
Output(s): Single
Maximum Current: 835mA
Input Voltage: 18V to 36V
Output Voltage: 12V
Efficiency: 83%
Protection: Short Circuit Protection (SCP)
Package: Tube
Temperature Range: -40°C to 60°C
Application: ITE (Commercial)
Standard Package: 200 pcs

Please note that the ASA00B24-L is an obsolete product.
