The HMC565LC5 from Analog Devices Inc. is a high-performance, wideband Double-Balanced Mixer, designed to operate from 6 GHz to 26 GHz. This mixer is a part of Analog Devices' Hittite Microwave Products, renowned for their exceptional quality and performance in the RF, microwave, and millimeter-wave domain.

Key Features

• Frequency Range: The HMC565LC5 offers a wide frequency range, making it suitable for a variety of applications including point-to-point and point-to-multipoint radios, test equipment, and sensors.
• Conversion Loss: With a typical conversion loss of 9 dB, this mixer maintains excellent performance across its entire operational bandwidth.
• LO/RF Isolation: It provides superior isolation between the LO and RF ports, significantly reducing potential interference.
• Input IP3: The HMC565LC5 boasts a high input third-order intercept point, which translates to improved linearity and dynamic range.
• Package: Encased in a compact 5x5 mm SMT package, the HMC565LC5 is designed for easy integration into a wide range of systems.

Applications

The versatility of the HMC565LC5 makes it an ideal choice for a multitude of RF applications. It is particularly well-suited for:

• Military and space
• Fiber optic applications
• Wireless infrastructure
• Test instrumentation

Quality and Reliability

Analog Devices Inc. is committed to providing products that meet the highest standards of quality and reliability. The HMC565LC5 is no exception, benefiting from Analog Devices' rigorous testing and quality control processes. Customers can trust in the dependable performance and longevity of this mixer for their critical applications.

Technical Support and Resources

Comprehensive technical documentation, application notes, and design resources for the HMC565LC5 are available on the Analog Devices website. Additionally, Analog Devices' support team is available to assist with any technical inquiries or integration challenges that may arise.
