Product Overview: HMC264LC3BTR by Analog Devices Inc.

The HMC264LC3BTR is a high-performance, passive double-balanced mixer from Analog Devices Inc., designed to provide exceptional RF and IF frequency range coverage. This versatile component is a vital part of RF and microwave signal chains, commonly used in applications such as wireless communications, satellite and space communications, test equipment, and radar systems.

Key Features

• Wide Frequency Range: The mixer operates over a broad frequency range, supporting RF/LO frequencies from 11 to 20 GHz and IF frequencies from DC to 4 GHz, making it suitable for various high-frequency applications.
• Passive Design: Being a passive device, it does not require DC power for operation, which simplifies circuit design and enhances reliability.
• High Isolation: The HMC264LC3BTR offers excellent isolation between ports, minimizing signal leakage and preserving signal integrity.
• Compact Package: Encased in a compact 3x3 mm SMT package, the mixer is ideal for space-constrained applications where board real estate is at a premium.

Performance Specifications

Parameter Specification RF/LO Frequency Range 11 to 20 GHz IF Frequency Range DC to 4 GHz Conversion Loss Typically 9 dB LO to RF Isolation 42 dB typical LO to IF Isolation 40 dB typical Input IP3 +18 dBm typical Package 3x3 mm SMT

Applications

The HMC264LC3BTR is suitable for a wide array of high-frequency mixing applications, including but not limited to:

• Point-to-point and point-to-multipoint radios
• VSAT (Very Small Aperture Terminal)
• Military & Space
• Test Equipment
• Radar Systems

With its robust design and flexible operation, the HMC264LC3BTR from Analog Devices Inc. represents a reliable solution for engineers looking to optimize their high-frequency signal processing capabilities.
