Analog Devices Inc. ADUC834BSZ MicroConverter®

The ADUC834BSZ is a fully integrated 1 MSPS, 24-bit data acquisition system incorporating high performance multichannel analog-to-digital converters (ADCs), 8-channel multiplexer, and a programmable gain amplifier (PGA) alongside a microcontroller unit (MCU). Manufactured by Analog Devices Inc., a leader in high-performance semiconductors, this precision analog microcontroller is designed for direct interfacing to external precision sensors in both industrial and instrumentation applications.

The core of the ADUC834BSZ is an 8052 MCU which is an 8-bit processor that offers high flexibility and ease of use. It is equipped with 62 kB of nonvolatile Flash/EE memory, which is segmented and protected to enhance security and data retention. The microcontroller also features 4 kB of nonvolatile Flash/EE data memory, 2304 bytes of RAM, and dual 16-bit and 20-bit timer/counters.

Its high-resolution ADCs, with a PGA that is adjustable from 1 to 128 in 1-2-4-8-16-32-64-128 steps, provide a versatile front-end to a wide variety of sensor inputs. The ADCs can operate in single-ended or differential input modes, and the integrated temperature sensor adds to the versatility of the device. The fast conversion rate of 1 MSPS makes it suitable for high-speed signal processing applications.

For communication, the ADUC834BSZ includes an I²C-compatible serial interface, which allows for easy data transfer and connectivity with other devices in a system. It also features a serial I/O port for UART/USART operation, SPI (Serial Peripheral Interface), and a flexible 16-bit PWM (Pulse Width Modulation) block.

The device operates from a 2.7 V to 5.25 V power supply, ensuring compatibility with a wide range of applications, and is available in a 52-lead MQFP (Metric Quad Flat Pack) package. Its robust design includes a watchdog timer and power supply monitor, which contribute to the overall system reliability.

The ADUC834BSZ is ideal for demanding applications requiring high-precision data acquisition, such as process control, smart sensors, instrumentation, and medical systems. Its integration of analog and digital components on a single chip reduces system cost and complexity, making it a compelling solution for sophisticated measurement and control systems.
