The ADM3312EARUZ is a high-performance, low-power, RS-232/V.28 transceiver from Analog Devices Inc., designed to operate from a single 3.3V power supply. This makes it an ideal choice for portable or space-constrained applications such as laptops, PDAs, and other handheld devices. With its industry-standard footprint, the ADM3312EARUZ is a drop-in replacement for many existing RS-232 transceivers, offering enhanced performance and reduced power consumption.

Key Features:

• Low Voltage Operation: Operates from a single 3.3V power supply, making it suitable for battery-powered and portable applications.
• High Data Rate: Capable of supporting data rates up to 460 kbps, providing high-speed data transmission for a variety of communication applications.
• Low Power Consumption: Features a low-power shutdown mode that reduces power consumption to less than 1 µW, extending battery life in portable devices.
• ESD Protection: Equipped with ±15 kV ESD protection on transmitter outputs and receiver inputs, which safeguards the device against electrostatic discharge events.
• Integrated Charge Pump: Comes with an on-chip charge pump that generates the required RS-232 voltage levels from the 3.3V supply, eliminating the need for additional power supplies.
• Flexible Packaging: Available in a compact 28-lead TSSOP package, the ADM3312EARUZ saves valuable board space in densely packed designs.

Applications:

• Portable and handheld devices
• Notebook, sub-notebook, and palmtop computers
• Battery-powered equipment
• Data cable
• Peripherals

The ADM3312EARUZ transceiver from Analog Devices Inc. is an exemplary solution for designers looking to integrate reliable RS-232 communication in their systems with minimal power draw and maximum protection. With its robust feature set and compact design, this product is set to enhance the connectivity and performance of a wide array of electronic devices.
