Product Overview: ADG736BRMZ-REEL7

The ADG736BRMZ-REEL7 is a high-performance, dual SPDT (single pole double throw) switch fabricated by Analog Devices Inc., a leader in precision high-performance electronics. This switch is designed to operate from a single 1.8 V to 5.5 V supply, making it ideal for a wide range of applications in the consumer, industrial, and communication markets.

Key Features

• Low Voltage Operation: The ADG736BRMZ-REEL7 operates efficiently across a supply range of 1.8 V to 5.5 V, accommodating various battery-operated and portable devices.
• Low On-Resistance: With a typical on-resistance of just 4 ohms, this switch ensures minimal signal distortion and power loss, providing a high-fidelity signal path.
• Low Power Consumption: The device boasts ultra-low power consumption, with a typical power consumption of less than 0.01 μW, making it suitable for power-sensitive applications.
• Wide Operating Temperature Range: The ADG736BRMZ-REEL7 can operate over an extended temperature range of -40°C to +125°C, ensuring reliability and performance under extreme conditions.
• High Switching Speed: Fast transition times (tON and tOFF) of typically 20 ns and 30 ns, respectively, allow for quick signal switching, which is critical for high-speed data acquisition and multiplexing applications.

Applications

The versatility of the ADG736BRMZ-REEL7 makes it suitable for a variety of applications, including:

• Audio and video signal routing
• Communication systems
• Relay replacement
• Battery-powered systems
• Sample and hold systems
• Automotive infotainment

Quality and Packaging

Supplied in a compact 10-lead MSOP (Mini Small Outline Package), the ADG736BRMZ-REEL7 is designed with space-saving in mind without compromising on performance. It is available on a 7-inch reel, facilitating efficient integration into automated manufacturing processes. Analog Devices Inc. ensures that this product meets stringent quality standards, providing reliable and consistent performance.

With its combination of low power consumption, wide voltage range, and high switching speeds, the ADG736BRMZ-REEL7 represents a robust solution for designers looking to optimize their signal routing with minimal power loss and high signal integrity.
