The ADG1612BRUZ is a high-performance, quad single-pole single-throw (SPST) switch from Analog Devices Inc., designed for precision signal routing in a variety of applications. This component is part of the renowned ADG161x series, which is known for its reliability and versatility in handling analog and digital signals.

Constructed with Analog Devices' proprietary iCMOS® (industrial CMOS) technology, the ADG1612BRUZ combines high voltage tolerance with low power operation, making it an excellent choice for battery-powered devices and power-sensitive applications. The switch operates with a single supply voltage ranging from +3.3V to +5.5V, allowing for straightforward integration into most electronic systems.

Key Features of the ADG1612BRUZ

• Low On-Resistance: The device boasts a low on-resistance typically around 1.5 Ω, ensuring minimal signal attenuation when the switch is closed.
• High Off Isolation: With high off isolation, the ADG1612BRUZ prevents signal leakage between channels when the switch is in the off state, maintaining signal integrity.
• Low Power Consumption: Its low power consumption makes it suitable for portable and battery-operated devices, contributing to longer battery life.
• Wide Operating Temperature Range: The switch is designed to operate over an extended temperature range from -40°C to +125°C, making it reliable in harsh environmental conditions.
• Single Supply Operation: The ability to operate with a single supply voltage simplifies the power supply design and reduces component count.

Applications

The ADG1612BRUZ is ideal for a variety of applications including:

• Audio and video signal routing
• Data acquisition systems
• Communication systems
• Relay replacement
• Automatic test equipment

Offered in a compact TSSOP-14 package, the ADG1612BRUZ is engineered to occupy minimal board space while providing robust performance. Its package is RoHS compliant and designed for surface-mount technology (SMT), facilitating integration into automated manufacturing processes.

With its combination of performance, efficiency, and reliability, the ADG1612BRUZ from Analog Devices Inc. is a smart choice for designers seeking a high-quality switch for their next project.
