The ADE7758ARWZ-RL, from Analog Devices Inc., is a highly integrated polyphase multifunction energy metering IC designed to meet the needs of modern energy metering systems. It incorporates all the necessary features for accurate energy measurement and power quality monitoring in a compact, surface-mount package.

Key Features

• Three-Phase Measurement: The ADE7758ARWZ-RL is capable of measuring active, reactive, and apparent energy on three-phase electrical systems, making it versatile for various power distribution configurations.
• High Accuracy: Designed for high accuracy energy measurement, this IC ensures precise readings which are vital for billing and monitoring purposes.
• On-Chip DSP: With an integrated Digital Signal Processor, the device can perform complex calculations for energy and power quality measurements, reducing the need for external processing power.
• Multiple Communication Interfaces: It supports SPI and I²C communication protocols, allowing for easy integration with microcontrollers and other digital systems.

Applications

The ADE7758ARWZ-RL is suitable for a wide range of applications, including:

• Residential and commercial energy meters
• Industrial power monitoring systems
• Smart grid infrastructure
• Energy management systems

Product Specifications

The ADE7758ARWZ-RL operates over an industrial temperature range and comes in a 24-lead SOIC (RW-24) package. It requires a supply voltage of 5V and features a lead (Pb) free construction with a RoHS-compliant design.

Ordering Information

To order or inquire about the ADE7758ARWZ-RL, visit the Analog Devices Inc. website or contact an authorized distributor. The "-RL" suffix indicates that the product is offered in reel packaging, which is ideal for automated manufacturing processes.

Quality and Reliability

Analog Devices Inc. is renowned for its commitment to quality and reliability. The ADE7758ARWZ-RL is no exception, and it is manufactured to the highest industry standards to ensure performance and durability in the field.
