The AD9860BST is a sophisticated mixed-signal front-end (MxFE®) processor from the renowned manufacturer Analog Devices Inc. This versatile component is designed to cater to a wide array of communication applications, particularly excelling in broadband modem designs such as xDSL. The AD9860BST integrates a complete set of functionalities required for high-performance modem systems, thus streamlining design processes and improving overall system reliability.

Key Features

• High-Performance Analog Front-End: The device includes a 14-bit, 64 MSPS analog-to-digital converter (ADC) and a 14-bit, 128 MSPS digital-to-analog converter (DAC), providing high-resolution signal conversion that is essential for demanding communication applications.
• Digital Signal Processing: Equipped with digital downconversion and interpolation filters, the AD9860BST simplifies the digital interface to baseband processing units, reducing the need for complex external components.
• Programmable Filters: The product features programmable receive and transmit filters, allowing customization for specific application requirements, which enhances the flexibility and adaptability of the system design.
• Integrated PLL: An on-chip phase-locked loop (PLL) facilitates clock generation, reducing the need for external clocking components and simplifying the overall design.

Applications

The AD9860BST is particularly adept for use in broadband communication systems, including:

• xDSL modems, including ADSL, ADSL2, and VDSL
• Wireless local loop transceivers
• IF sampling receivers
• Cable modems
• Multi-carrier, multi-tone systems

Technical Specifications

The device boasts robust technical specifications that underscore its utility in high-speed data communication systems:

• Supply Voltage: 3.3V
• Operating Temperature Range: -40°C to +85°C
• Package: 100-Lead LQFP
• Part Number: AD9860BST

Conclusion

The AD9860BST from Analog Devices Inc. represents a powerful and efficient solution for advanced communication systems. With its high-speed ADC and DAC, flexible digital processing, and integrated PLL, this MxFE® processor is an invaluable asset for designers looking to achieve high performance in broadband modem applications.
