AD8422ARZ

Part No AD8422ARZ
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP INSTR 2.2MHZ RRO 8SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Tube/Rail
Status Active
Amplifier Type Instrumentation
Number of Circuits 1
Output Type Rail-to-Rail
Slew Rate 0.8 V/μs
-3db Bandwidth 2.2MHz
Current - Input Bias 500pA
Voltage - Input Offset 60μV
Operating Supply Current 300μA
Channel Output Current 20mA
Supply Voltage - Operating 3.6 V to 36 V, ±1.8 V to 18 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 008463-AD8422ARZ
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AD8422ARZ CAD Model

Description

AD8422ARZ from Analog Devices Inc. is a component in the Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps category, typically considered for precision signal conditioning, sensor interface design, and measurement front ends where stable amplification and low-level analog accuracy are important. Engineers may evaluate this device for industrial control systems, medical instrumentation, test equipment, and bridge-based sensing applications that require dependable analog performance from a recognized supplier. Its value is generally tied to the need for accurate amplification in space-constrained or performance-sensitive designs, especially when system designers want to simplify front-end analog stages with a dedicated amplifier solution. The current lifecycle status for AD8422ARZ is information not available in the provided data, so design teams should confirm latest production status directly with Analog Devices Inc. before committing to new programs. RoHS compliance information is also not available in the provided input and should be verified using the official datasheet, declaration of conformity, or manufacturer compliance documentation.
