The AD622ARZ is a low cost, high precision instrumentation amplifier from Analog Devices Inc. that offers excellent accuracy and ease of use. This device is designed to amplify small differential voltages in the presence of large common-mode signals, making it ideal for a wide range of applications, including medical instrumentation, industrial process controls, and precision data acquisition systems.

Key Features

• High Precision: With a high accuracy of ±0.15% max at G = 1 (G is the gain), the AD622ARZ ensures precise measurements for critical applications.
• Wide Supply Range: Operating on a supply range from ±2.3 V to ±18 V, the AD622ARZ is versatile and can be used in a variety of power environments.
• Adjustable Gain: The gain of the AD622ARZ can be set from 2 to 1000 by a single external resistor, which provides flexibility in amplification levels for different applications.
• Low Power: Consuming only 1.3 mA of supply current, this instrumentation amplifier is suitable for battery-powered and portable equipment due to its low power consumption.
• Single Resistor Gain Set: The AD622ARZ simplifies circuit design by allowing the gain to be set with a single external resistor, minimizing external component count.

Applications

The AD622ARZ is optimized for use in environments where high common-mode rejection is required. It is commonly employed in:

• Medical instrumentation such as ECG and non-invasive blood pressure monitors.
• Industrial process controls including transducer interfaces, 4 mA to 20 mA loop-powered systems, and strain gauge amplifiers.
• Data acquisition systems where precision is essential, such as weigh scales and transducer interfaces.

Package and Quality

The AD622ARZ is packaged in an 8-lead SOIC (Small Outline Integrated Circuit) form factor, providing a compact solution for space-constrained applications. Analog Devices Inc. is known for its commitment to quality, and this product is no exception, ensuring reliable performance in demanding environments.
