The AD585SE from Analog Devices Inc. is a state-of-the-art, high precision sample-and-hold amplifier designed to address the rigorous requirements of fast data acquisition systems and analog-to-digital converters (ADCs). This high-performance component is essential for applications where precise signal acquisition and timing accuracy are paramount.

Key Features

• High Accuracy: The AD585SE boasts exceptional accuracy with low droop rate and aperture error, ensuring the integrity of the sampled signal is maintained over time.
• Fast Acquisition Time: With a swift acquisition time, this device is capable of quickly capturing the signal of interest, making it ideal for high-speed applications.
• Low Power Consumption: Designed for efficiency, the AD585SE offers a low power consumption profile, which is critical for minimizing heat generation in densely packed electronic systems.
• Monolithic Construction: The monolithic construction of the AD585SE enhances its reliability and performance consistency, contributing to the overall robustness of the system it is integrated into.
• Wide Operating Temperature Range: The device is designed to operate effectively across a broad temperature range, ensuring stable performance in varying environmental conditions.

Applications

The AD585SE is an ideal component for a variety of precision applications, including:

• Data Acquisition Systems
• Medical Instrumentation
• Industrial Process Controls
• Military and Aerospace Electronics

Technical Specifications

The AD585SE comes in a robust package that meets the rigorous demands of industrial and military-grade applications. It provides a high level of integration, which simplifies design and enhances overall system reliability. Below are some of the technical specifications:

• Supply Voltage: ±15 V
• Acquisition Time: 1.5 µs to 0.01%
• Hold Mode Droop Rate: 2 mV/ms
• Aperture Delay: 20 ns
• Operating Temperature Range: -55°C to +125°C

For engineers and system designers seeking a reliable and high-performing sample-and-hold amplifier, the AD585SE from Analog Devices Inc. offers a compelling solution that combines precision, speed, and durability.
