The AD5293BRUZ-20 from Analog Devices Inc. is a high-performance digital potentiometer that offers a full 20-bit resolution for precise control over your signal conditioning applications. Designed to provide an accurate and stable variable resistance, this compact component is ideal for calibration and adjustable gain circuits in a wide range of industrial, automotive, and consumer electronics.

Key Features

• High Resolution: 20-bit resolution for precise adjustments.
• Wide Voltage Range: Operates from a 2.7V to 5.5V single supply, making it versatile for various applications.
• Low Temperature Coefficient: Ensures minimal deviation with temperature changes, providing stable performance across a wide temperature range.
• Nonvolatile Memory: Settings can be stored in onboard memory, ensuring persistence of the resistance setting even after power-down.
• Compact Package: Housed in a small 14-lead TSSOP (thin shrink small outline package), it is suitable for space-constrained applications.
• Robust Interface: Features a serial interface that is compatible with SPI, QSPI™, MICROWIRE™, and DSP interface standards for easy integration into existing systems.

Applications

The AD5293BRUZ-20 is highly adaptable and can be used in various applications, including:

• Programmable Filters and Delays
• Calibration and Gain Adjustment Circuits
• Power Supply Control
• Automotive Electronics Adjustments
• Portable Instrumentation

Product Specifications

With its high resolution, robust interface, and nonvolatile memory, the AD5293BRUZ-20 is a superior choice for precision control in your next design project.
