Product Overview: ADG619BRMZ from Analog Devices Inc.

The ADG619BRMZ is a high-performance, CMOS analog switch manufactured by Analog Devices Inc., a leader in precision high-performance integrated circuits. This particular model is part of the ADG619 series, which is known for its low power consumption and high switching speeds, making it an excellent choice for a wide range of applications.

This analog switch features a dual single-pole, single-throw (SPST) configuration, offering flexibility for routing and signal management in complex circuits. The device operates with a single supply voltage ranging from +2.7V to +5.5V, which is ideal for battery-powered and portable devices where power efficiency is crucial. Additionally, the ADG619BRMZ boasts a low on-resistance of typically 0.8 ohms, ensuring minimal signal distortion and loss.

The ADG619BRMZ comes in a compact MSOP (Mini Small Outline Package) with 10 pins, designated by the "RMZ" suffix in its part number. This small footprint allows for high-density mounting and is suitable for space-constrained applications. Furthermore, the device features fast switching times with a t<sub>ON of 16 ns and a t<sub>OFF of 10 ns, contributing to efficient signal processing and rapid response times in critical applications.

The switch is designed with break-before-make switching action, which prevents momentary shorting when switching channels. This characteristic is particularly important in applications such as sample and hold circuits, where signal integrity is paramount. Additionally, the ADG619BRMZ has an extended operating temperature range from -40°C to +85°C, making it reliable in diverse environmental conditions.

Typical applications for the ADG619BRMZ include data acquisition systems, communication systems, audio and video switching, test equipment, and relay replacements. Its high performance and reliability make it a preferred choice for designers looking for a switch that offers both precision and durability.

Analog Devices Inc. provides comprehensive technical support and documentation for the ADG619BRMZ, ensuring that engineers can integrate this component into their designs with confidence and efficiency.
