AD5246BKS5-R2 Digital Potentiometer by Analog Devices Inc.

The AD5246BKS5-R2 is a precision digital potentiometer manufactured by the renowned Analog Devices Inc., a company known for its high-performance analog, mixed-signal, and digital signal processing integrated circuits (ICs). This particular model offers robust performance and reliability for a wide range of applications.

Featuring a compact SOT-23 5-lead package, the AD5246BKS5-R2 provides a two-channel, 256-position digitally controlled variable resistor device. This allows for precise adjustment of resistance values through an I2C-compatible digital interface, which makes it an excellent choice for applications that require fine-tuning of resistance settings in a space-constrained environment.

Key Features:

• Resolution: The digital potentiometer offers a high resolution with 256 positions, enabling fine adjustments to the resistance level.
• Interface: It features an I2C-compatible serial interface, facilitating easy communication with microcontrollers and other digital systems.
• Power Supply: The device operates on a wide single-supply voltage range of 2.7V to 5.5V, making it versatile for various power environments.
• End-to-End Resistance: The AD5246BKS5-R2 has an end-to-end resistance of 10 kΩ, which is ideal for a multitude of applications requiring a standard resistance range.
• Temperature Range: It is designed to function over an extended industrial temperature range, ensuring reliable operation under varying environmental conditions.
• Packaging: The small SOT-23 package is suitable for space-saving designs and can be easily incorporated into compact PCB layouts.

With its precision and programmability, the AD5246BKS5-R2 is perfect for applications such as adjustable power supplies, LCD screen calibration, and audio control. Its robustness and ease of use also make it a favorable choice for automotive systems, industrial automation, and test equipment.

Analog Devices Inc. ensures that the AD5246BKS5-R2 meets the stringent quality standards expected of their products. With the combination of its features and the manufacturer's reputation, this digital potentiometer is an excellent component for designers looking to add reliable and precise variable resistance control to their electronic designs.
