97-4102A-16S-1P Amphenol
Same model may have multiple batches, images only for reference.

97-4102A-16S-1P

Part No 97-4102A-16S-1P
Manufacturer Amphenol
Catalog HOT - SALES and EOL Components (0 - A)
Description Conn Circular PIN 7 POS Crimp ST Box Mount 7 Terminal 1 Port Automotive Medical
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer AMPHENOL
Body Orientation Straight
Contact Plating Silver
Operating Temp Range -55C to 125C
Shell Size / Insert Arrangement 16S-1
Shell Plating Bright Cadmium
Family 97
Contact Gender PIN
Product Length (mm) 24.21(mm)
Product Depth (mm) 32.54(mm)
Product Height (mm) 32.54(mm)
Rad Hardened No
Product Diameter (mm) Not Required(mm)
Gender RCP
Strain Relief No
Type MIL-C-5015 Circular
Termination Method Crimp
Contact Classification 7Signal
Mounting Style Box
Contact Material Copper Alloy
Number of Contacts 7(POS)
Win Source Part Number 051403-97-4102A-16S-1P
Popularity Low
Supply and Demand Status Limited
Family Name 97
Introduction Date November 10, 2003
ECCN EAR99
Country of Origin China, Germany, Mexico
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian 97-4102A-16S-1P CAD Model

Description

Description

The 97-4102A-16S-1P connector is designed to provide excellent connectivity solutions for complex electronic systems. It is built to ensure seamless connections and durability under tough conditions.

  • Features: High-strength materials, Precision connectivity, Easy installation
  • Benefits: Long-term durability, Reliable signal transmission, Efficient assembly
  • Applications: Industrial electronics, Telecommunications, Automotive systems

Engineers trust this connector for applications where reliable performance is crucial, making it suitable for demanding environments.
