66506-007LF Real Image
Same model may have multiple batches, images only for reference.

66506-007LF

Part No 66506-007LF
Manufacturer Amphenol
Catalog Rectangular Connectors
Description CONN HEADER VERT 20POS 2.54MM / Connector Header Through Hole 20 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Amphenol ICC (FCI)
Series Quickie™
Package Tray
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 20
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Type Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.230" (5.84mm)
Contact Length - Post 0.105" (2.67mm)
Insulation Height 0.365" (9.27mm)
Contact Shape Square
Contact Finish - Mating Gold or Gold, GXT™
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Contact Material Phosphor Bronze
Insulation Material Polyester, Glass Filled
Features Keying Slot
Material Flammability Rating UL94 V-0
Insulation Color Black
Base Product Number 66506
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 66506-007LF-ND,609-5850
Standard Package 30
Win Source Part Number 1011216-66506-007LF
Ultra Librarian 3D Model Ultra Librarian 66506-007LF CAD Model

Description

The 1011216-66506-007LF from Amphenol ICC (FCI) is a 20-position header connector.

  • Positions: 20
  • Series: Quickie™
  • Keying Slot: Yes
  • Pitch: 0.100" (2.54mm)
  • Application: Board-to-cable/wire
  • Design: Shrouded 4-wall
  • Compatible Contact Gender: Male pin
  • Insulation Material: Polyester and glass-filled
  • Flammability Rating: UL94 V-0
  • Contact Finish: Gold or gold GXT™
  • Contact Finish Thickness: 30.0μin (0.76μm)
  • Reliable and Secure Connection: Suitable for use in various applications that require a reliable and secure connection.
