54202-S0803LF Real Image
Same model may have multiple batches, images only for reference.

54202-S0803LF

Part No 54202-S0803LF
Manufacturer Amphenol
Catalog Circular Connectors - Housings
Description CONN HEADER SMD 6POS 2.54MM / Connector Header Surface Mount 6 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Amphenol ICC (FCI)
Series BERGSTIK®
Package Bag
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 6
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Board
Shrouding Unshrouded
Mounting SMD (SMT)
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.230" (5.84mm)
Insulation Height 0.100" (2.54mm)
Contact Shape Square
Contact Finish - Mating Gold or Gold, GXT™
Contact Finish Thickness - Mating 15.0µin (0.38µm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Temperature Range - Operating -65°C ~ 130°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 3A
Contact Finish Thickness - Post 100.0µin (2.54µm)
Base Product Number 54202
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names 2266-54202-S0803LF
Standard Package 100
Win Source Part Number 1171862-54202-S0803LF
Ultra Librarian 3D Model Ultra Librarian 54202-S0803LF CAD Model

Description

The Amphenol ICC (FCI) 54202-S0803LF is a rectangular connector header with male pins.

  • Series: BERGSTIK
  • Number of Positions: 6
  • Connector Type: Header
  • Contact Type: Male Pin
  • Positions Loaded: All
  • Number of Rows: 2
  • Termination: Solder
  • Fastening Type: Push-Pull
  • Package: Bag
  • Standard Package: 100
  • Contact Material: Phosphor Bronze
  • Insulation Material: Black
  • Voltage Rating: -
  • Temperature Range: -65°C ~ 130°C
