67800-5001 Real Image
Same model may have multiple batches, images only for reference.

67800-5001

Part No 67800-5001
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn SATA PL 7 POS 1.27mm Solder ST SMD 7 Terminal 1 Port Frame
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type SATA
Contact Material Brass
Contact Plating Gold
Contact Resistance 30 mΩ
Country of Origin US
Current Rating 500 mA
Depth 6.45 mm
Gender Male
Height 9.85 mm
Housing Color Black
Housing Material Thermoplastic
Length 42.73 mm
Max Operating Temperature 85 °C
Max Voltage Rating (AC) 15 V
Min Operating Temperature -55 °C
Mount Surface Mount
Number of Circuits 50
Number of Contacts 7
Number of Ports 1
Number of Positions 7
Number of Rows 1
Number of Terminals 7
Orientation Vertical
Pitch 1.27 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Solder
Voltage Rating 15 V
Voltage Rating (DC) 15 V
Win Source Part Number 1169789-67800-5001
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 67800-5001 CAD Model

Description

This 7-position SATA connector from Molex is a high-quality and durable solution for your computer hardware needs.

  • Positions: 7
  • Pitch: 1.27mm
  • Win Source part number: 1169789-67800-5001
  • Gender: male
  • Length: 42.73mm
  • Housing Material: thermoplastic
  • Contact Material: brass with gold plating
  • Rated for: 15V and 500mA
  • Category: circular connector housings
  • Popularity: medium
  • RoHS compliant: Yes
  • Minimum Operating Temperature: -55°C
