Part No AXK6S40647YG
Manufacturer Panasonic
Catalog Circular Connectors - Housings
Description CONN HDR 40POS SMD GOLD  /  40 Position Connector Header, Outer Shroud Contacts Surface Mount Gold
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
Mfr Panasonic Electric Works
Series P5KS
Package Tape & Reel
Connector Type Header, Outer Shroud Contacts
Number of Positions 40
Pitch 0.020" (0.50mm)
Number of Rows 2
Mounting SMD (SMT)
Contact Finish Gold
Mated Stacking Heights 6mm, 6.5mm, 9mm
Height Above Board 0.209" (5.30mm)
Base Product Number AXK6S40647
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names 255-2542-6,255-2542-2,255-2542-1
Standard Package 1,000
Win Source Part Number 1170638-AXK6S40647YG
Ultra Librarian 3D Model Ultra Librarian AXK6S40647YG CAD Model

Description

This rectangular connector array is part of the P5KS series and is manufactured by Panasonic Electric Works.

  • Win Source Part Number: The Win Source Part Number for this product is 1170638-AXK6S40647YG.
  • Positions: The connector has 40 positions and a pitch of 0.020" (0.50mm).
  • Connection Type: It is designed for board-to-board mezzanine connections.
  • Supply and Demand Status: The supply and demand status is balanced.
  • Plating: The connector is gold-plated and has a height above board of 0.209" (5.30mm).
  • Datasheet: For more details, please refer to the manufacturer's datasheet.
