11355

Part No 11355
Manufacturer Amphenol-RF Division
Catalog Coaxial Connectors (RF)
Description CONN BNC PLUG STR 50 OHM SOLDER
Datasheet
11355 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Amphenol RF Division
Packaging Bulk
Connector Style BNC
Connector Type Plug, Male Pin
Contact Termination Solder
Shield Termination Clamp
Impedance 50 Ohm
Mounting Free Hanging (In-Line)
Cable Group RG-58, 58A, 58B, 58C, 141, 303, LMR-195, Belden B7806A, 9907
Fastening Type Bayonet Lock
Frequency - Max 4GHz
Housing Color Silver
Includes 6 pcs - 1 Connector, 1 Braid Clamp, 1 Clamp, 1 Contact, 1 Gasket, 1 Washer
Body Material Brass
Body Finish Nickel
Center Contact Plating Silver
Dielectric Material Polytetrafluoroethylene (PTFE)
Operating Temperature Range -65°C ~ 165°C
Center Contact Material Brass
Voltage Rating 500V
Mating Cycles 500
Insertion Loss 0.2dB
Win Source Part Number 793117-11355
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 11355 CAD Model

Description

The Amphenol RF Division BNC connector is a bayonet lock type plug from Amphenol RF Division.

  • Type: Plug, male pin
  • Termination: Solder Contact
  • Impedance: 50 Ohm
  • Voltage Rating: 500V
  • Cable Groups: RG-58, 58A, 58B, 58C, 141, 303, LMR-195, Belden B7806A, 9907
  • Insertion Loss: 0.2dB
  • Mating Cycles: 500
  • Body Material: Brass
  • Body Finish: Nickel
  • Center Contact Material: Brass
  • Center Contact Plating: Silver
  • Dielectric Material: PTFE
  • Pieces: 6 (1 connector, 1 braid clamp, 1 clamp, 1 contact, 1 gasket, 1 washer)
  • Applications: Connectors, Interconnects
