EPM570T100A5N Real Image EPM570T100A5N Real Image
Same model may have multiple batches, images only for reference.
EPM570T100A5N Real Image EPM570T100A5N Real Image
EPM570T100A5N Real Image EPM570T100A5N Real Image
Same model may have multiple batches, images only for reference.

EPM570T100A5N

Part No EPM570T100A5N
Manufacturer Altera
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description IC CPLD 440MC 5.4NS 100TQFP / CPLD MAX® II Family 440 Macro Cells 201.1MHz 0.18um Technology 2.5V/3.3V Automotive 100-Pin TQFP Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Altera
Series MAX II
Packaging Tray
Programmable Type In System Programmable
Delay Time tpd(1) Max 5.4ns
Voltage Supply - Internal 2.5V, 3.3V
Number of Logic Elements/Blocks 570
Number of Macrocells 440
Number of I/O 76
Operating Temperature Range -40°C ~ 125°C (TJ)
Mounting SMD
Package 100-TQFP
Manufacturer Package 100-TQFP (14x14)
Win Source Part Number 774132-EPM570T100A5N
Popularity Medium
Supply and Demand Status Limited
Quantity per package 90
Family Name EPM570
Introduction Date December 21, 2004
ECCN EAR99
Country of Origin Malaysia
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian EPM570T100A5N CAD Model

Description

The Altera MAX II series is a family of programmable logic devices designed to provide high-performance solutions for a wide range of applications. It has an estimated end-of-life date of 2027.

  • Package: 100-TQFP
  • I/O Pins: 76
  • Voltage Supply: 2.5V to 3.3V
  • Maximum Operating Temperature: 125°C
  • Logic Elements/Blocks: 570
  • Macrocells: 440
  • Programmable: In-system
  • Delay Time: 5.4ns
  • Estimated end-of-life date: 2027
