EPM3064ATC100-4N Real Image EPM3064ATC100-4N Real Image1 EPM3064ATC100-4N Real Image2 EPM3064ATC100-4N Real Image3 EPM3064ATC100-4N Real Image4 EPM3064ATC100-4N Real Image5 EPM3064ATC100-4N Real Image6 EPM3064ATC100-4N Real Image7
Same model may have multiple batches, images only for reference.
EPM3064ATC100-4N Real Image EPM3064ATC100-4N Real Image1 EPM3064ATC100-4N Real Image2 EPM3064ATC100-4N Real Image3 EPM3064ATC100-4N Real Image4 EPM3064ATC100-4N Real Image5 EPM3064ATC100-4N Real Image6 EPM3064ATC100-4N Real Image7
EPM3064ATC100-4N Real Image EPM3064ATC100-4N Real Image1 EPM3064ATC100-4N Real Image2 EPM3064ATC100-4N Real Image3 EPM3064ATC100-4N Real Image4 EPM3064ATC100-4N Real Image5 EPM3064ATC100-4N Real Image6 EPM3064ATC100-4N Real Image7
Same model may have multiple batches, images only for reference.

EPM3064ATC100-4N

Part No EPM3064ATC100-4N
Manufacturer Altera
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description IC CPLD 64MC 4.5NS 100TQFP
Datasheet
EPM3064ATC100-4N Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Altera
Series MAX 3000A
Packaging Tray
Programmable Type In System Programmable
Delay Time tpd(1) Max 4.5ns
Voltage Supply - Internal 3 V ~ 3.6 V
Number of Logic Elements/Blocks 4
Number of Macrocells 64
Number of Gates 1250
Number of I/O 66
Operating Temperature Range 0°C ~ 70°C (TA)
Mounting SMD
Package 100-TQFP
Manufacturer Package 100-TQFP (14x14)
Manufacturer Homepage www.altera.com
RoHS State Request Verification
Win Source Part Number 758824-EPM3064ATC100-4N
Popularity Medium
Supply and Demand Status Limited
Family Name EPM3064A
ECCN EAR99
Country of Origin Malaysia, Philippines
Halogen Free Compliant
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian EPM3064ATC100-4N CAD Model

Description

The Altera EPM3064ATC100-4N is an integrated circuit (IC) manufactured by Altera.

  • Series: MAX 3000A
  • Programmable: In-system
  • Delay Time tpd(1) max: 4.5ns
  • Voltage Supply - Internal: 3 V to 3.6 V
  • Gates: 1250
  • Logic Elements/Blocks: 4
  • Macrocells: 64
  • Family: EPM3064A
  • Package: 100-TQFP
  • Status: Obsolete (EOL)
  • Supply and Demand: Limited
