AP4 Altech corporation
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Switches - Configurable Switch Components - Body
Mfr Altech Corporation
Package Bulk
Product Status Active
Requires Contact Block(s)
Type Momentary
Illumination Non-Illuminated
Actuator Type Pushbutton, Round
(Select First, Then Apply Filters) Compatible Series Altech, 30mm
Panel Cutout Dimensions 30.5mm (Round)
Standard Package 2 pcs
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8538.90.8180
California Prop 65 Warning Information
Win Source Part Number 563018-AP4
Ultra Librarian 3D Model Ultra Librarian AP4 CAD Model

Description

The 563018-AP4 is a momentary pushbutton switch component designed for use in configurable switches.

  • Actuator: It features a round pushbutton actuator and is non-illuminated.
  • Requirement: The switch requires contact block(s) and is compatible with Altech's 30mm series.
  • Panel Cutout Dimensions: 30.5mm
  • Package: Packaged in bulk with a standard package of 2 pcs.
  • Manufacturer: Altech Corporation
  • Status: Currently active in the market.
  • REACH Regulations: Not affected
  • ECCN Classification: EAR99
  • California Prop 65: In compliance
  • HTSUS Code: 8538.90.8180
