ACS770LCB-100B-PFF-T

Part No ACS770LCB-100B-PFF-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 100A AC/DC
Datasheet
ACS770LCB-100B-PFF-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Current Sensors
Mfr Allegro MicroSystems, LLC
Series ACS770
Package Tube
Product Status Active
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 100A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 20mV/A
Frequency DC ~ 120kHz
Linearity ±1%
Accuracy ±0.6%
Voltage - Supply 5V
Response Time 4.6µs
Current - Supply (Max) 15mA
Temperature Range - Operating -40°C ~ 150°C
Polarization Bidirectional
Mounting Type Through Hole
Package / Case 5-CB Formed Leads, PFF
Supplier Device Package 5-CB Module
Base Product Number ACS770
Standard Package 34 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 844536-ACS770LCB-100B-PFF-T
Ultra Librarian 3D Model Ultra Librarian ACS770LCB-100B-PFF-T CAD Model

Description

The ACS770LCB-100B-PFF-T is a current sensor designed for measuring AC and DC currents up to 100A. This ACS770LCB-100B-PFF-T utilizes the Hall Effect principle and features an open-loop sensor type.

  • Current Measurement: AC and DC up to 100A
  • Sensor Type: Hall Effect, Open-Loop
  • Sensitivity: 20mV/A
  • Supply Voltage: 5V
  • Current Consumption: 15mA
  • Output: Ratiometric, Voltage-Based
  • Package: Through-Hole
  • Series: ACS770
  • Temperature Range: -40°C to 150°C
