ACS758KCB-150B-PFF-T Allegro MicroSystems, LLC ACS758KCB-150B-PFF-T real image17075 ACS758KCB-150B-PFF-T Real Image1 ACS758KCB-150B-PFF-T Real Image2 ACS758KCB-150B-PFF-T Real Image3
Same model may have multiple batches, images only for reference.
ACS758KCB-150B-PFF-T Allegro MicroSystems, LLC ACS758KCB-150B-PFF-T real image17075 ACS758KCB-150B-PFF-T Real Image1 ACS758KCB-150B-PFF-T Real Image2 ACS758KCB-150B-PFF-T Real Image3
ACS758KCB-150B-PFF-T Allegro MicroSystems, LLC ACS758KCB-150B-PFF-T real image17075 ACS758KCB-150B-PFF-T Real Image1 ACS758KCB-150B-PFF-T Real Image2 ACS758KCB-150B-PFF-T Real Image3
Same model may have multiple batches, images only for reference.

ACS758KCB-150B-PFF-T

Part No ACS758KCB-150B-PFF-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description Thermally Enhanced, Fully Integrated, Hall Effect-Based Linear Current Sensor IC with 100 μΩ Current Conductor
Datasheet
ACS758KCB-150B-PFF-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Series Automotive, AEC-Q100
Packaging Tube
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 150A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 13.3mV/A
Frequency DC ~ 120kHz
Linearity ±1%
Accuracy ±1.6%
Operating Supply Voltage 3 V ~ 5.5 V
Response Time 4μs
Maximum Supply Current 13.5mA
Operating Temperature Range -40°C ~ 125°C
Polarization Bidirectional
Mounting Style Through Hole
Package 5-CB Formed Leads, PFF
Win Source Part Number 1135520-ACS758KCB-150B-PFF-T
Manufacturer Homepage www.allegromicro.com
Popularity Medium
Supply and Demand Status Balance
Family Name ACS758KCB
Introduction Date March 26, 2009
ECCN EAR99
Country of Origin Philippines
Halogen Free Not Compliant
Estimated EOL Date 2019
Ultra Librarian 3D Model Ultra Librarian ACS758KCB-150B-PFF-T CAD Model

Description

The Allegro MicroSystems ACS758KCB-150B-PFF-T is an automotive-grade, AEC-Q100 compliant, hall effect-based current sensor IC.

  • Manufacturer: Allegro MicroSystems
  • Compliance: Automotive-grade, AEC-Q100
  • Type: Hall effect-based current sensor IC
  • Sensing: AC/DC Current
  • Sensitivity: 13.3mV/A
  • Sensing Range: 150A
  • Output: Ratiometric and Voltage-based
  • Linearity: ±1%
  • Accuracy: ±1.6%
  • Operating Temperature: -40°C to 125°C
  • Response Time: 4μs
  • Mounting: Through-Hole
  • Package: 5-CB formed leads, PFF
  • Operating Supply Voltage: 3V to 5.5V
  • Maximum Supply Current: 13.5mA
  • Supply and Demand Status: Balanced
