ACS730KLCTR-50AB-T Real Image ACS730KLCTR-50AB-T real image21494 ACS730KLCTR-50AB-T Real Image1 ACS730KLCTR-50AB-T Real Image2 ACS730KLCTR-50AB-T Real Image3
Same model may have multiple batches, images only for reference.
ACS730KLCTR-50AB-T Real Image ACS730KLCTR-50AB-T real image21494 ACS730KLCTR-50AB-T Real Image1 ACS730KLCTR-50AB-T Real Image2 ACS730KLCTR-50AB-T Real Image3
ACS730KLCTR-50AB-T Real Image ACS730KLCTR-50AB-T real image21494 ACS730KLCTR-50AB-T Real Image1 ACS730KLCTR-50AB-T Real Image2 ACS730KLCTR-50AB-T Real Image3
Same model may have multiple batches, images only for reference.

ACS730KLCTR-50AB-T

Part No ACS730KLCTR-50AB-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description 1MHZ BANDWIDTH INTEGRATED, HALL
Datasheet
ACS730KLCTR-50AB-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Packaging Reel package
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 50A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 40mV/A
Frequency 1MHz
Linearity ±0.75%
Accuracy ±3%
Operating Supply Voltage 4.5 V ~ 5.5 V
Response Time 700ns
Maximum Supply Current 25mA
Operating Temperature Range -40°C ~ 125°C
Polarization Bidirectional
Mounting SMD
Package 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 766995-ACS730KLCTR-50AB-T
Popularity Medium
Supply and Demand Status Limited
Family Name ACS730
Introduction Date February 29, 2016
ECCN EAR99
Country of Origin Philippines
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian ACS730KLCTR-50AB-T CAD Model

Description

The ACS730KLCTR-50AB-T is a Hall Effect, open loop sensor manufactured by Allegro MicroSystems, LLC.

  • Sensitivity: 40mV/A
  • Current Sensing: 50A
  • Output: ratiometric voltage
  • Polarization: bidirectional
  • Package: 8-SOIC
  • Mounting: SMD
  • Response Time: 700ns
  • Operating Temperature Range: -40°C to 125°C
  • Estimated EOL Date: 2026
  • Popularity: medium
