ACS723LLCTR-20AB-T Real Image ACS723LLCTR-20AB-T Real Image
Same model may have multiple batches, images only for reference.
ACS723LLCTR-20AB-T Real Image ACS723LLCTR-20AB-T Real Image
ACS723LLCTR-20AB-T Real Image ACS723LLCTR-20AB-T Real Image
Same model may have multiple batches, images only for reference.

ACS723LLCTR-20AB-T

Part No ACS723LLCTR-20AB-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 20A AC/DC / Current Sensor 20A 1 Channel Hall Effect, Open Loop Bidirectional 8-SOIC (0.154", 3.90mm Width)
Datasheet
ACS723LLCTR-20AB-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Current Sensors
Mfr Allegro MicroSystems, LLC
Package Tape & Reel
Product Status Active
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 20A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 100mV/A
Frequency DC ~ 80kHz
Linearity ±1%
Accuracy ±3%
Voltage - Supply 5V
Response Time 5µs
Current - Supply (Max) 14mA
Temperature Range - Operating -40°C ~ 150°C
Polarization Bidirectional
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SOIC
Base Product Number ACS723
Standard Package 3,000 pcs
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 845608-ACS723LLCTR-20AB-T
Ultra Librarian 3D Model Ultra Librarian ACS723LLCTR-20AB-T CAD Model

Description

The ACS723LLCTR-20AB-T is a current sensor designed for various applications. It is part of Allegro MicroSystems' ACS723 series of current sensors.

  • Package: Tape & Reel
  • Standard Package: 3,000 pieces
  • Status: Active
  • ECCN: EAR99
  • Sensor Type: Hall Effect
  • Output Type: Ratiometric Voltage
  • Polarization: Bidirectional
  • Sensing Range: 20A
  • Voltage Supply: 5V
  • Maximum Supply Current: 14mA
  • Response Time: 5µs
  • Frequency Range: DC to 80kHz
  • Manufacturer: Allegro MicroSystems, LLC
