N7E50-7516PG-20 3M
Same model may have multiple batches, images only for reference.

N7E50-7516PG-20

Part No N7E50-7516PG-20
Manufacturer 3M
Catalog Memory Connectors - PC Card Sockets
Description CONN COMPACT FLASH CARD R/A SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Memory Connectors - PC Card Sockets
Mfr 3M
Series 7E50
Package Bulk
Product Status Active
Card Type CompactFlash® - Type I
Number of Positions 50
Connector Type Connector
Insertion, Removal Method Push In, Pull Out
Mounting Type Surface Mount, Right Angle
Features Board Guide, Card Guide
Height Above Board 0.261" (6.64mm)
Mounting Feature Normal, Standard - Top
Contact Finish Gold
Contact Finish Thickness Flash
Base Product Number N7E50
Standard Package 100 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 747873-N7E50-7516PG-20
Ultra Librarian 3D Model Ultra Librarian N7E50-7516PG-20 CAD Model

Description

The 747873-N7E50-7516PG-20 is a PC Card socket connector from 3M.

  • Application: memory
  • For: CompactFlash® - Type I cards
  • Series: 7E50
  • Positions: 50
  • Contact Plating: gold
  • Mounting Type: surface mount, right-angle
  • Packaging: bulk
  • Standard Package: 100 pieces
  • Height Above Board: 0.261" (6.64mm)
  • Operating Temperature Range: -40°C to 85°C
  • ECCN: EAR99
