Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Board In, Direct Wire to Board
Mfr 3M
Series 78XX
Package Bulk
Connector Type Ribbon Cable, DIP Header
Number of Positions 64
Cable Pitch 0.050" (1.27mm)
Board-Side Pitch 0.100" (2.54mm)
Number of Rows 2
Row Spacing 0.100" (2.54mm)
Mounting Type Through Hole
Cable Termination IDC
Wire Gauge 26 AWG, Stranded; 28 AWG, Solid or Stranded; 30 AWG, Solid
Features Feed Through
Contact Finish Gold
Contact Finish Thickness Flash
Color Gray
Number of Positions Loaded All
Base Product Number 7864
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names 7000090302,-7864-0000PR,78640000PR,0-45-47452-26312-7,4547452263127,54745226312,JE150319109
Standard Package 100
Win Source Part Number 1039651-7864-0000PR
Ultra Librarian 3D Model Ultra Librarian 7864-0000PR CAD Model

Description

The 78XX series rectangular connector is a board-in, direct wire-to-board connector that is used for electronic devices.

  • Positions: 64
  • Color: Gray
  • Design: Feed-Through
  • Connector Type: Ribbon Cable, DIP Header
  • Positions Loaded: All
  • Rows: 2
  • Row Spacing: 0.100" (2.54mm)
  • Contact Finish: Gold
  • Contact Finish Thickness: Flash
  • Package: Bulk
  • Standard Package: 100
  • Wire Gauge: 26 AWG, Stranded; 28 AWG, Solid or Stranded; 30 AWG, Solid
  • Termination: IDC
  • Cable Pitch: 0.050" (1.27mm)
  • Board-Side Pitch: 0.100" (2.54mm)
  • Mounting Type: Through-Hole
  • ECCN: EAR99
  • REACH: Unaffected
  • HTSUS: 8536.69.4040
  • Manufacturer: 3M
