The CJP12N65 is a high voltage N-channel MOSFET from ZP Semiconductor. It is designed for high-efficiency switching applications.

Applications:

• Switch Mode Power Supplies (SMPS)
• Power Factor Correction (PFC) circuits
• Uninterruptible Power Supplies (UPS)
• DC-DC converters
• LED lighting

Features:

• High voltage: 650V
• Low on-resistance (RDS(on))
• Fast switching speed
• High ruggedness
• Avalanche rated

Benefits:

• High efficiency
• Reduced power loss
• Improved system reliability
• Simplified thermal management
• Cost-effective solution

Technical Specifications:

The CJP12N65 is an N-channel MOSFET with a voltage rating of 650V. It features a low on-resistance, which minimizes conduction losses. The fast switching speed reduces switching losses. It is designed for through-hole mounting. For complete specifications, including drain current, gate charge, and thermal resistance, refer to the ZP Semiconductor datasheet.

This MOSFET is commonly used in power supply applications due to its high voltage rating, low on-resistance, and fast switching characteristics. Note that this part is marked as END-OF-LIFE.
