CJ78M15

Part No CJ78M15
Manufacturer ZP Semiconductor
Catalog END - OF - LIFE
Description TO-251/TO-252-2L Plastic-Encapsulate Regulators
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer ZP Semiconductor
Win Source Part Number 1161628-CJ78M15
Manufacturer Homepage zpsemi.com/
Ultra Librarian 3D Model Ultra Librarian CJ78M15 CAD Model

Description

The CJ78M15 is a three-terminal positive voltage regulator from ZP Semiconductor. It's designed to provide a fixed output voltage of 15V, making it suitable for a variety of applications requiring stable power. This series of regulators is widely used due to its simplicity and built-in protection features.

Applications:

  • Linear Power Supplies: Used in basic regulated power supplies to provide a stable 15V output.
  • Battery Chargers: Can be implemented in simple battery charging circuits to maintain a consistent voltage.
  • On-card Regulation: Provides localized voltage regulation for sensitive components on a PCB.
  • Industrial Control Systems: Provides stable voltage for sensors, actuators, and other control circuitry.
  • DIY Electronics Projects: Commonly used in hobbyist projects requiring a clean and stable 15V supply.

Features:

  • Fixed Output Voltage: Provides a precise and stable 15V output.
  • Internal Short-Circuit Current Limiting: Protects the regulator and the load from damage in case of a short circuit.
  • Thermal Overload Protection: Shuts down the regulator if the internal temperature exceeds a safe limit, preventing overheating and damage.
  • Output Transistor Safe-Area Compensation: Enhances the reliability of the regulator by preventing damage to the output transistor.
  • Requires Only External Components: Typically requires only input and output capacitors for stable operation.

Benefits:

  • Simplified Power Supply Design: Reduces the complexity of power supply design due to its ease of use and minimal external components.
  • Enhanced System Reliability: Improves the reliability of electronic systems by providing a stable and regulated voltage.
  • Protection Against Fault Conditions: Protects the regulator and the load from damage due to short circuits and thermal overload.
  • Cost-Effective Solution: Provides a cost-effective solution for voltage regulation in a wide range of applications.
  • Improved Circuit Performance: Ensures optimal performance of electronic circuits by providing a clean and stable power source.

The CJ78M15 typically requires only two external capacitors for stable operation: a bypass capacitor on the input and an output capacitor to improve transient response. The regulator is available in various packages, such as TO-220, allowing for easy mounting and heat sinking. The regulator's robust design and comprehensive protection features make it a reliable choice for providing a stable 15V supply in diverse electronic applications.
