DTC114EUA Real Image
Same model may have multiple batches, images only for reference.

DTC114EUA

Part No DTC114EUA
Manufacturer Yangzhou yangjie electronic co., ltd
Catalog Transistors (BJT) - Single, Pre - Biased
Description SOT-323 NPN 0.2W 0.1A Transisto / Pre-Biased Bipolar Transistor (BJT) NPN - Pre-Biased + Diode 50 V 100 mA 250 MHz 200 mW Surface Mount SOT-323
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - Bipolar (BJT) - Single, Pre-Biased Bipolar Transistors
Mfr Yangzhou yangjie electronic co., ltd
Package Tape & Reel
Product Status Active
Transistor Type NPN - Pre-Biased + Diode
Current - Collector (Ic) (Max) 100 mA
Voltage - Collector Emitter Breakdown (Max) 50 V
Resistor - Base (R1) 10 kOhms
DC Current Gain (hFE) (Min) @ Ic, Vce 30 @ 5mA, 5V
Vce Saturation (Max) @ Ib, Ic 300mV @ 500µA, 10mA
Current - Collector Cutoff (Max) 500nA
Frequency - Transition 250 MHz
Power - Max 200 mW
Mounting Type Surface Mount
Package / Case SC-70, SOT-323
Supplier Device Package SOT-323
Base Product Number DTC114
Standard Package 3,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
Win Source Part Number 587533-DTC114EUA
Ultra Librarian 3D Model Ultra Librarian DTC114EUA CAD Model

Description

The 587533-DTC114EUA is a pre-biased bipolar transistor designed for various electronic applications.

  • Product Name: 587533-DTC114EUA
  • Type: Pre-biased Bipolar Transistor
  • Transistor Type: NPN
  • Collector-Emitter Breakdown Voltage: 50 V
  • Power Dissipation: 200 mW
  • DC Current Gain: 30 @ 5 mA and 5V
  • Collector Cutoff Current: 500 nA
  • Transition Frequency: 250 MHz
  • Mounting: Surface Mount
  • Package: SC-70 (SOT-323)
  • Manufacturer: Yangzhou yangjie electronic co., ltd
  • Product Status: Active
