The RC0603DR-07470RL is a thick film chip resistor manufactured by Yageo. It is designed for general-purpose applications in electronic circuits where a stable and reliable resistance value is needed. The 0603 designation indicates its compact size, making it suitable for high-density circuit board designs.

Applications

• Consumer electronics: Used in smartphones, tablets, digital cameras, and other portable devices.
• Computer peripherals: Employed in devices like keyboards, mice, and printers.
• Telecommunications equipment: Utilized in modems, routers, and other networking devices.
• Industrial control systems: Found in process controllers, motor drives, and power supplies.
• Medical devices: Used in patient monitoring systems, diagnostic equipment, and therapeutic devices.

Features

• Small Size (0603): Allows for compact and high-density circuit board designs.
• Thick Film Construction: Offers stable and reliable resistance values.
• Wide Resistance Range: Available in a variety of resistance values to meet different circuit requirements.
• High Reliability: Designed for long-term stability and performance in various environments.
• RoHS Compliant: Meets environmental regulations for hazardous substances.

Benefits

• Space Savings: Small size allows for more components to be placed on a circuit board, reducing overall size and weight.
• Stable Performance: Thick film construction ensures consistent and reliable resistance values over the operational lifespan.
• Versatile Application: Suitable for a wide range of electronic circuits and applications due to its stable and reliable performance.
• Long-Term Reliability: Designed to withstand harsh environmental conditions and provide continuous, dependable operation.
• Environmentally Friendly: RoHS compliance ensures the product does not contain hazardous substances, contributing to environmental protection.

Additional Details

The RC0603DR-07470RL has a resistance value of 470 Ohms. The power rating is typically 1/10W (0.1W). The tolerance is 0.5%. The temperature coefficient of resistance (TCR) is typically ±100 ppm/°C. The standard operating temperature range is -55°C to +155°C. The dimensions of the 0603 package are 0.6mm x 0.3mm. It is designed for reflow soldering processes. More details, including voltage rating and maximum operating temperature, can be found in the datasheet.
