AC0402JR-0747RL

Name: AC0402JR-0747RL
Brand: Yageo
SKU: 1236318
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	AC0402JR-0747RL
Manufacturer	Yageo
Catalog	Chip Resistor - Surface Mount
Description	RES SMD 47 OHM 5% 1/16W 0402 / 47 Ohms ±5% 0.063W, 1/16W Chip Resistor 0402 (1005 Metric) Automotive AEC-Q200, Moisture Resistant Thick Film
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Resistors>Chip Resistor - Surface Mount
Mfr	YAGEO
Series	AC
Package	Tape & Reel
Resistance	47 Ohms
Tolerance	±5%
Power (Watts)	0.063W, 1/16W
Composition	Thick Film
Features	Automotive AEC-Q200, Moisture Resistant
Temperature Coefficient	±100ppm/°C
Temperature Range - Operating	-55°C ~ 155°C
Package / Case	0402 (1005 Metric)
Supplier Device Package	0402
Ratings	AEC-Q200
Dimension	0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max)	0.015" (0.37mm)
Number of Terminations	2
Other Names	AC0402JR-0747RL,YAG3548DKR,YAG3548TR,YAG3548CT
Standard Package	10,000
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8533.21.0030
Win Source Part Number	1236318-AC0402JR-0747RL
Ultra Librarian 3D Model	Ultra Librarian AC0402JR-0747RL CAD Model

Alternative Products

Description

The AC0402JR-0747RL is a chip resistor surface mount electronic component belonging to the AC series. It is an automotive AEC-Q200 and moisture-resistant component.

Package: Tape & Reel
Height - Seated (Max): 0.015" (0.37mm)
Standard Package: 10,000
Tolerance: ±5%
Temperature Coefficient: ±100ppm/°C
Ratings: AEC-Q200
Power (Watts): 0.063W, 1/16W
Composition: Thick Film
Number of Terminations: 2
Resistance: 47 ohms
Package/Case: 0402 (1005 Metric)
Supplier Device Package: 0402
Manufacturer: YAGEO
Win Source Part Number: 1236318-AC0402JR-0747RL
Temperature Range - Operating: -55°C ~ 155°C
