XC95216-20HQ208I Real Image
Same model may have multiple batches, images only for reference.

XC95216-20HQ208I

Part No XC95216-20HQ208I
Manufacturer Xilinx Inc.
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description 10 ns pin-to-pin logic delays on all pins
Datasheet
XC95216-20HQ208I Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Xilinx Inc.
Series XC9500
Packaging Tray
Part Status Obsolete(EOL)
Programmable Type In System Programmable (min 10K program/erase cycles)
Delay Time tpd(1) Max 20.0ns
Voltage Supply - Internal 4.5 V ~ 5.5 V
Number of Logic Elements/Blocks 12
Number of Macrocells 216
Number of Gates 4800
Number of I/O 166
Operating Temperature Range -40°C ~ 85°C (TA)
Mounting SMD
Package 208-BFQFP Exposed Pad
Manufacturer Package 208-PQFP (28x28)
Win Source Part Number 1281956-XC95216-20HQ208I
Manufacturer Homepage www.xilinx.com
Popularity Medium
Supply and Demand Status Limited
Family Name XC95216
Introduction Date May 01, 1996
ECCN EAR99
Country of Origin Republic of Korea, Taiwan
Halogen Free Compliant
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian XC95216-20HQ208I CAD Model

Description

The XC95216-20HQ208I is an integrated circuit from the XC9500 series manufactured by Xilinx Inc.

  • Programmable Type: In System Programmable (min 10K program/erase cycles)
  • Internal Voltage Supply: 4.5 V to 5.5 V
  • I/Os: 166
  • Gates: 4800
  • Logic Elements/Blocks: 12
  • Mounting Style: SMD
  • Package: 208-BFQFP Exposed Pad
  • Temperature Range: -40°C to 85°C (TA)
  • Delay Time tpd(1) max: 20.0ns
  • Macrocells: 216
  • Status: obsolete
