XC7Z020-2CLG400E Real Image XC7Z020-2CLG400E real image15580 XC7Z020-2CLG400E real image15581 XC7Z020-2CLG400E real image15582
Same model may have multiple batches, images only for reference.
XC7Z020-2CLG400E Real Image XC7Z020-2CLG400E real image15580 XC7Z020-2CLG400E real image15581 XC7Z020-2CLG400E real image15582
XC7Z020-2CLG400E Real Image XC7Z020-2CLG400E real image15580 XC7Z020-2CLG400E real image15581 XC7Z020-2CLG400E real image15582
Same model may have multiple batches, images only for reference.

XC7Z020-2CLG400E

Part No XC7Z020-2CLG400E
Manufacturer Xilinx Inc.
Catalog Embedded - System On Chip (SoC)
Description IC SOC CORTEX-A9 766MHZ 400BGA
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Xilinx Inc.
Packaging Tray
Architecture MCU, FPGA
Core Processor Dual ARM Cortex -A9 MPCore with CoreSight
RAM Size 256KB
Peripherals DMA
Connectivity CANbus, EBI/EMI, Ethernet, I2C, MMC/SD/SDIO, SPI, UART/USART, USB OTG
Speed 766MHz
Primary Attributes Artix -7 FPGA, 85K Logic Cells
Temperature Range - Operating 0°C ~ 100°C
Manufacturer Package 400-LFBGA, CSPBGA
Supplier Device Package 400-CSPBGA (17x17)
Number of I/O 130
Part Number Series XC7Z020
Manufacturer Pack Quantity 90
MSL Level 3 (168 Hours)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 806481-XC7Z020-2CLG400E
Ultra Librarian 3D Model Ultra Librarian XC7Z020-2CLG400E CAD Model

Description

The Xilinx Inc. XC7Z020-2CLG400E is a high-performance FPGA.

  • Family: Artix-7
  • Processor: Dual ARM Cortex-A9 MPCore with CoreSight, 766MHz
  • Logic Cells: 85K
  • RAM: 256KB
  • Package: 400-CSPBGA (17x17)
  • Temperature Range: 0°C to 100°C
  • Popularity: Medium
  • Supply and Demand Status: Balanced
  • Connectivity: CANbus, Ethernet, USB OTG
