XFHCL6-1R0M XFMRS Inc.
Same model may have multiple batches, images only for reference.

XFHCL6-1R0M

Part No XFHCL6-1R0M
Manufacturer XFMRS Inc.
Catalog Fixed Inductors
Description FIXED IND 1UH 11A 10 MOHM SMD
Datasheet
XFHCL6-1R0M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr XFMRS Inc.
Series XFHCL6
Package Tape & Reel
Product Status Active
Type Molded
Inductance 1 µH
Tolerance ±20%
Current Rating (Amps) 11 A
Current - Saturation (Isat) 22A
Shielding Shielded
DC Resistance (DCR) 10mOhm Max
Frequency - Self Resonant 55MHz
Ratings AEC-Q200
Temperature Range - Operating -55°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting Type Surface Mount
Size / Dimension 0.280" L x 0.260" W (7.10mm x 6.60mm)
Height - Seated (Max) 0.118" (3.00mm)
Standard Package 1 pcs
MSL Level 1 (Unlimited)
HTSUS 8504.50.8000
Win Source Part Number 699417-XFHCL6-1R0M
Ultra Librarian 3D Model Ultra Librarian XFHCL6-1R0M CAD Model

Description

The XFHCL6 series molded inductors are designed to provide reliable and efficient performance in a compact package.

  • Size: 0.280" L x 0.260" W (7.10mm x 6.60mm)
  • Type: Shielded
  • Inductance: 1μH
  • Tolerance: ±20%
  • Seated Height: 0.118" (3.00mm)
  • Current: 11A
  • DC Resistance (DCR): 10mΩ max
  • Mounting Type: Surface Mount
  • Packaging: Tape and Reel
  • Operating Temperature Range: -55°C to 125°C
  • MSL Level: 1
  • HTSUS Code: 8504.50.8000
  • Manufacturer: XFMRS Inc.
  • Status: Active
