The NCE7190A is an N-channel enhancement mode power MOSFET manufactured by Wuxi NCE Power Semiconductor Co., Ltd. It is designed for high-efficiency switching applications, offering low on-resistance and fast switching speed. This MOSFET is commonly used in power supplies, DC-DC converters, and motor control circuits.

Applications

• Power supplies: Used in switching power supplies for computers, servers, and other electronic devices.
• DC-DC converters: Implemented in DC-DC converters for voltage regulation in various applications.
• Motor control circuits: Employed in motor control circuits for controlling the speed and torque of motors.
• LED lighting: Utilized in LED lighting applications for efficient power switching.
• Battery management systems (BMS): Integrated into BMS for controlling battery charging and discharging.

Features

• N-channel enhancement mode: Provides efficient switching performance.
• Low on-resistance (RDS(on)): Minimizes power loss and improves efficiency.
• Fast switching speed: Enables high-frequency switching operation.
• Avalanche rated: Withstands avalanche conditions for improved reliability.
• RoHS compliant: Environmentally friendly, meeting RoHS standards.

Benefits

• High efficiency: Low on-resistance and fast switching speed improve energy efficiency.
• Reliable operation: Avalanche rating ensures robust performance in demanding applications.
• Easy integration: Standard package and pinout simplify integration into existing designs.
• Versatile applications: Suitable for a wide range of power switching applications.
• Environmentally friendly: RoHS compliance ensures environmental responsibility.

Specifications

The NCE7190A has a drain-source voltage (VDS) rating of 70V and a continuous drain current (ID) rating of 90A. The on-resistance (RDS(on)) is typically 6.5 mΩ at VGS = 10V. It is available in a TO-220 package for through-hole mounting. The operating temperature range is typically -55°C to +175°C.

This power MOSFET provides a high-performance, high-efficiency solution for various power switching applications. Its low on-resistance, fast switching speed, and avalanche rating make it an excellent choice for modern electronic devices. The RoHS compliance ensures environmental responsibility.
