7448640413

Part No 7448640413
Manufacturer Wurth Electronics Inc
Catalog Common Mode Chokes
Description CMC 5.6MH 800MA 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 5.6 mH @ 10 kHz
Current Rating (Max) 800mA
DC Resistance (DCR) (Max) 415mOhm (Typ)
Voltage Rating - AC 250V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Through Hole
Size / Dimension 0.835" L x 0.654" W (21.20mm x 16.60mm)
Height (Max) 0.886" (22.50mm)
Case / Package Vertical, 4 PC Pin
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1507203-7448640413
Ultra Librarian 3D Model Ultra Librarian 7448640413 CAD Model
