744242510 Real Image 744242510 real image16971 744242510 real image16972
Same model may have multiple batches, images only for reference.
744242510 Real Image 744242510 real image16971 744242510 real image16972
744242510 Real Image 744242510 real image16971 744242510 real image16972
Same model may have multiple batches, images only for reference.

744242510

Part No 744242510
Manufacturer Wurth Electronics Inc
Catalog Common Mode Chokes
Description COMMON MODE SMD LINE FILTER WE-SLM | CMC 51UH 400MA 2LN 2.5 KOHM SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Filters
Manufacturer Wurth Electronics Inc.
Packaging Reel
Filter Type Signal Line
Number of Lines 2
Impedance at Frequency 2.5 kOhms at 25MHz
Inductance at Frequency 51μH at 100kHz
Current Rating (Maximum) 400mA
DC Resistance (DCR) (Maximum) 320mOhm
Voltage Rating - DC 80V
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Parts Dimension 0.236" L x 0.130" W (6.00mm x 3.30mm)
Height (Maximum) 0.138" (3.50mm)
Manufacturer Package Horizontal, 4 Flat Lead
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1129927-744242510
Manufacturer Homepage www.we-online.com
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian 744242510 CAD Model

Description

The Wurth Electronics Inc. 744242510 is a high-quality electronic component that is designed to provide reliable filtering of signal lines.

  • Maximum Current Rating: 400mA
  • DC Resistance: 320mOhm
  • Manufacturer: Wurth Electronics Inc.
  • Description: An excellent choice for anyone looking for a reliable and high-quality electronic component.
