744222 Real Image 744222 real image 744222 real image 2
Same model may have multiple batches, images only for reference.
744222 Real Image 744222 real image 744222 real image 2
744222 Real Image 744222 real image 744222 real image 2
Same model may have multiple batches, images only for reference.

744222

Part No 744222
Manufacturer Wurth Electronics Inc
Catalog Common Mode Chokes
Description CMC 1MH 800MA 2LN 6KOHM SMD
Datasheet
744222 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters - Common Mode Chokes
Mfr Wurth Electronics Inc
Series WE-SL2
Package Tape & Reel
Product Status Active
Filter Type Power, Signal Line
Number of Lines 2
Impedance @ Frequency 6 kOhms @ 4 MHz
Inductance @ Frequency 1 mH @ 100 kHz
Current Rating (Max) 800mA
DC Resistance (DCR) (Max) 310mOhm
Voltage Rating - DC 80V
Temperature Range - Operating -40°C ~ 125°C
Ratings AEC-Q200
Mounting Type Surface Mount
Size / Dimension 0.362" L x 0.236" W (9.20mm x 6.00mm)
Height (Max) 0.209" (5.30mm)
Package / Case Horizontal, 4 PC Pad
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8548.00.0000
Win Source Part Number 547222-744222
Ultra Librarian 3D Model Ultra Librarian 744222 CAD Model

Description

The WE-SL2 series is a range of common mode chokes designed for power and signal line filtering applications from Wurth Electronics Inc.

  • Size: 0.362" L x 0.236" W (9.20mm x 6.00mm)
  • Impedance: 6 kOhms @ 4 MHz
  • Inductance: 1 mH @ 100 kHz
  • Voltage Rating: 80V DC
  • Current Rating: 800mA
  • Mounting: Surface mount
  • Height: 0.209" (5.30mm) max
  • DC Resistance (DCR): 310mOhm max
  • Operating Temperature Range: -40°C to 125°C
  • Package: Tape & Reel
  • Standard Package: 1,000 pcs
  • Applications: Power supplies, communication systems, and automotive electronics
