The 1332207-231-634 electronic component is a terminal block header manufactured by WAGO Corporation.

• Category: Connectors, interconnects>terminal blocks>headers, plugs and sockets
• Packaging: Box
• Type: Plug with male pins
• Positions per level: 4
• Level: 1
• Pitch: 0.200" (5.08mm)
• Plug wire entry: 180°
• Termination style: Screwless - spring cage, tension clamp
• Current-IEC: 12A
• Voltage-IEC: 630V
• Current-UL: 15A
• Voltage-UL: 600V
• Wire gauge or range - AWG: 12-28 AWG
• Wire gauge or range - mm2: 0.08-2.5mm²
• Color: Orange
• Contact mating finish: Tin
• Contact material: Electrolytic copper
• Housing material: Polyamide (PA66), nylon 6/6
• Material flammability rating: UL94 V-0
• Standard package: 1
• Mounting type: Free hanging (in-line)
• Temperature range: -60°C ~ 100°C
• Wire strip length: 8-9mm
