VS-E5PH3006L-N3

Part No VS-E5PH3006L-N3
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 600V 30A TO247AD
Datasheet
VS-E5PH3006L-N3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr Vishay General Semiconductor - Diodes Division
Series FRED Pt®
Package Tube
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 600 V
Current - Average Rectified (Io) 30A
Voltage - Forward (Vf) (Max) @ If 1.6 V @ 30 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 46 ns
Current - Reverse Leakage @ Vr 20 µA @ 600 V
Capacitance @ Vr, F -
Mounting Type Through Hole
Package / Case TO-247-2
Supplier Device Package TO-247AD
Operating Temperature - Junction -55°C ~ 175°C
Base Product Number E5PH3006
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 1367914-VS-E5PH3006L-N3
Ultra Librarian 3D Model Ultra Librarian VS-E5PH3006L-N3 CAD Model

Description

The 1367914-VS-E5PH3006L-N3 is a single diode rectifier from Vishay General Semiconductor - Diodes Division's FRED Pt series.

  • Manufacturer: Vishay General Semiconductor - Diodes Division
  • Series: FRED Pt
  • Product: 1367914-VS-E5PH3006L-N3
  • Maximum DC Reverse Voltage (Vr): 600 V
  • Average Rectified Current (Io): 30A
  • Forward Voltage (Vf): 1.6V @ 30A
  • Recovery Time (trr): 46 ns
  • Package: TO-247-2
  • Device Package: TO-247AD
  • Mounting Type: Through-Hole
  • Operating Temperature Range: -55°C to 175°C
  • Product Status: Active
  • REACH Regulations: Unaffected
