VS-8ETH06PBF Real Image VS-8ETH06PBF Real Image
Same model may have multiple batches, images only for reference.
VS-8ETH06PBF Real Image VS-8ETH06PBF Real Image
VS-8ETH06PBF Real Image VS-8ETH06PBF Real Image
Same model may have multiple batches, images only for reference.

VS-8ETH06PBF

Part No VS-8ETH06PBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description Hyperfast Rectifier, 8 A FRED Pt® | DIODE GEN PURP 600V 8A TO220AC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Semiconductor Diodes Division
Packaging Tube
Diode Type Standard
Voltage - DC Reverse (Vr) (Maximum) 600V
Current - Average Rectified (Io) 8A
Voltage - Forward (Vf) (Maximum) at If 2.4V at 8A
Speed Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 25ns
Current - Reverse Leakage at Vr 50μA at 600V
Mounting Style Through Hole
Manufacturer Package TO-220-2
Supplier Device Package TO-220AC
Operating Temperature - Junction -65°C ~ 175°C
Family Part Number 8ETH06
Manufacturer Pack Quantity 50
MSL Level 1 (Unlimited)
Win Source Part Number 1279832-VS-8ETH06PBF
Manufacturer Homepage www.nichicon-us.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian VS-8ETH06PBF CAD Model

Description

The Vishay Semiconductor Diodes Division VS-8ETH06PBF is a through-hole diode with a voltage rating of 600V and an average rectified current of 8A.

  • Voltage Rating: 600V
  • Average Rectified Current: 8A
  • Forward Voltage: 2.4V @ 8A
  • Reverse Recovery Time: 25ns
  • Mounting: Mounted in a TO-220AC package
  • Operating Temperature Range: -65°C to 175°C
  • Recovery Speed: 200mA (Io)
  • Reverse Leakage Current: 50μA @ 600V
  • Family: Part of the 8ETH06 family
  • Suitability: Suitable for use in discrete semiconductor products.
