VB30100S-E3/8W Vishay VB30100S-E3/8W Real Image VB30100S-E3/8W label picture 2 VB30100S-E3/8W real image
Same model may have multiple batches, images only for reference.
VB30100S-E3/8W Vishay VB30100S-E3/8W Real Image VB30100S-E3/8W label picture 2 VB30100S-E3/8W real image
VB30100S-E3/8W Vishay VB30100S-E3/8W Real Image VB30100S-E3/8W label picture 2 VB30100S-E3/8W real image
Same model may have multiple batches, images only for reference.

VB30100S-E3/8W

Part No VB30100S-E3/8W
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description Rectifier Diode Schottky 100V 30A 3-Pin(2+Tab) TO-263AB T/R / DIODE SCHOTTKY 100V 30A TO263AB
Datasheet
VB30100S-E3/8W Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 30A
Voltage - Forward (Vf) (Max) @ If 910mV @ 30A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 1mA @ 100V
Mounting SMD (SMT)
Case / Package TO-263AB
Operating Temperature - Junction -40°C to 150°C
Win Source Part Number 130990-VB30100S-E3/8W
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Commercial, Power Management, Industrial
Family Name VB30100S
Introduction Date August 23, 2006
ECCN EAR99
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian VB30100S-E3/8W CAD Model

Description

The supply and demand status is limited, making it difficult to purchase.

  • Performance: Designed to provide stable performance
  • Application: Suitable for use in various electronic applications, especially those that require fast recovery
  • Maximum Voltage: 100V
  • Average Rectified Current: 30A
  • Compliance: RoHS compliant
  • Estimated EOL Date: 2026
