V30120C-E3/4W Vishay V30120C-E3/4W real image V30120C-E3/4W real image 2
Same model may have multiple batches, images only for reference.
V30120C-E3/4W Vishay V30120C-E3/4W real image V30120C-E3/4W real image 2
V30120C-E3/4W Vishay V30120C-E3/4W real image V30120C-E3/4W real image 2
Same model may have multiple batches, images only for reference.

V30120C-E3/4W

Part No V30120C-E3/4W
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description Rectifier Diode Schottky 120V 30A 3-Pin(3+Tab) TO-220AB Tube / DIODE ARRAY SCHOTTKY 120V TO220
Datasheet
V30120C-E3/4W Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 120V
Current - Average Rectified (Io) (per Diode) 15A
Voltage - Forward (Vf) (Max) @ If 970mV @ 15A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 800μA @ 120V
Operating Temperature - Junction -40°C to 150°C
Mounting Through Hole
Case / Package TO-220AB
Win Source Part Number 056971-V30120C-E3/4W
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name V30120C
Introduction Date September 05, 2007
ECCN EAR99
Country of Origin China
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian V30120C-E3/4W CAD Model

Description

The electronic component with Id 404361 is manufactured by Vishay. Its Win Source Part Number is 056971-V30120C-E3/4W.

  • Voltage - DC Reverse (Vr) (Max): 120V
  • Voltage - Forward (Vf) (Max) @ If: 970mV @ 15A
  • Current - Reverse Leakage @ Vr: 800μA @ 120V
  • Operating Temperature - Junction: -40°C to 150°C
  • Diode Configuration: 1 pair common cathode
  • Current - Average Rectified (Io) (per diode): 15A
  • Family: V30120C
  • Category: Discrete Semiconductor Products
  • Status: Active
  • Case/Package: TO-220AB
  • Speed (Frequency): Fast Recovery = 200mA (Io)
  • Supply and Demand: Balanced
