Same model may have multiple batches, images only for reference.
TSOP57238TT1 Real Image
Same model may have multiple batches, images only for reference.

TSOP57238TT1

Part No TSOP57238TT1
Manufacturer Vishay
Catalog Optical Sensors - Photo Detectors - Remote Receiver
Description SENSOR REMOTE REC 38.0KHZ 40M
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Vishay Semiconductor Opto Division
Packaging Reel
Sensing Distance 40m
B.P.F. Center Frequency 38.0kHz
Supply Voltage (V) 2.5V ~ 5.5V
Current - Supply 700μA
Orientation Top View
Mounting Style SMD
Temperature Range - Operating -25°C ~ 85°C
Manufacturer Pack Quantity 1,800
MSL Level 3 (168 Hours)
Popularity Low
Supply and Demand Status Limited
Win Source Part Number 813663-TSOP57238TT1
Ultra Librarian 3D Model Ultra Librarian TSOP57238TT1 CAD Model

Description

The TSOP57238TT1 is a top view surface-mount infrared receiver module from Vishay Semiconductor Opto Division.

  • Sensing Distance: 40m
  • B.P.F. Center Frequency: 38.0kHz
  • Supply Voltage: 2.5V to 5.5V
  • Current Supply: 700μA
  • Packaging: Reel
  • Manufacturer Pack Quantity: 1,800
  • Temperature Range: -25°C to 85°C
  • MSL Level: 3 (168 hours)
