TCMT1600 Real Image TCMT1600 label picture TCMT1600 real image TCMT1600 real image7163 TCMT1600 real image7164 TCMT1600 Real Image1 TCMT1600 Real Image2 TCMT1600 Real Image3
Same model may have multiple batches, images only for reference.
TCMT1600 Real Image TCMT1600 label picture TCMT1600 real image TCMT1600 real image7163 TCMT1600 real image7164 TCMT1600 Real Image1 TCMT1600 Real Image2 TCMT1600 Real Image3
TCMT1600 Real Image TCMT1600 label picture TCMT1600 real image TCMT1600 real image7163 TCMT1600 real image7164 TCMT1600 Real Image1 TCMT1600 Real Image2 TCMT1600 Real Image3
Same model may have multiple batches, images only for reference.

TCMT1600

Part No TCMT1600
Manufacturer Vishay
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Optocoupler AC-IN 1-CH Transistor DC-OUT 4-Pin SOP / OPTOISOLATOR 3.75KV TRANS 4-SOP
Datasheet
TCMT1600 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Vishay
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 80% @ 5mA
Maximum DC Current Transfer Ratio 300% @ 5mA
Switching Turn-On and Turn-Off Time 6μs, 5μs
Rise and Fall Time 3μs, 4.7μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 70V
Channel Output Current 50mA
Forward Voltage 1.35V
Continuous forward current- Max 60mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Case / Package 4-SOP
Win Source Part Number 032044-TCMT1600
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name TCMT1600
Introduction Date November 20, 2003
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian TCMT1600 CAD Model

Description

The Vishay TCMT1600 is an isolator with a transistor output type.

  • Forward Voltage: 1.35V
  • Isolation Voltage: 3750Vrms
  • Number of Channels: 1
  • Switching Turn-On Time: 6μs
  • Switching Turn-Off Time: 5μs
  • Rise Time: 3μs
  • Fall Time: 4.7μs
  • Maximum Output Voltage: 70V
  • Channel Output Current: 50mA
  • Continuous Forward Current max: 60mA
  • Minimum DC Current Transfer Ratio: 80% @ 5mA
  • Maximum DC Current Transfer Ratio: 300% @ 5mA
  • Operating Temperature: from -40°C to 100°C
  • Mounting Style: SMD (SMT)
  • Package: 4-SOP
  • Supply and Demand Status: limited
